P/N
CA-1Q5-00M1WN-00
Series
V Series
Model
V250 TG ARGB
CASE TYPE
Middle tower
Dimension (H x W x D)
477 x 216.5x 430 mm
(18.78 x 8.52 x 16.9 inch)
NET WEIGHT
6.06 kg / 13.36 lbs
PANEL
4mm Tempered Glass x 1
Color
Exterior & Interior : Black
MATERIAL
SPCC
COOLING SYSTEM
Front (intake) :
3 x 120 x 120 x 25mm Addressable RGB fan
(Fixed 1000rpm, 27.2 dBA)
Rear (exhaust) :
1 x 120 x 120 x 25 mm fan
(Fixed 1000rpm, 16dBA)
Drive Bays
-Accessible
-Hidden
2 x 3.5ā or 2 x 2.5ā
2 x 2.5ā
EXPANSION SLOTS
7
MOTHERBOARDS
6.7ā x 6.7ā (Mini ITX), 9.6ā x 9.6ā (Micro ATX), 12ā x 9.6ā (ATX)
I/O Port
USB 3.0 x 1, USB 2.0 x 2, HD Audio x 1, R Button x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
3 x 120mm, 3 x 140mm
Top:
2 x 120mm, 2 x 140mm
Rear:
1 x 120mm
RADIATOR SUPPORT
Front: 1 x 360mm, 1 x 280mm
Top: 1 x 240mm,
Rear: 1 x 120mm
CLEARANCE
CPU cooler height limitation: 160mm
VGA length limitation: 320mm
PSU length limitation:
160mm (With HDD Rack)
200mm (Without HDD Rack)
