The optimized pump design features an efficient 3-phase, 6-slot, 4-pole motor that rotates up to an astounding 3400 RPM, while staying under a quiet 21 dB(A).
REDESIGNED AND IMPROVED COLDPLATE
The MYSTIQUE 360 gets a redesigned coldplate that has been optimized for better heat transfer and 0.1mm intensive flow channels. The layout has been placed over CPU hotspots, and a precise liquid splitter makes sure that everything is flowing efficiently.
NEW HIGH PERFORMANCE FT12 SE FANS
The MYSTIQUE 360 will include three high-performing black FT12 SE PWM fans. These fans are made of durable PBT material and provide excellent pressure and airflow. They also utilize the tried-and-true FDB bearings that are considered the gold standard in our industry. The fan motor will utilize a 3-phase 6-slot 4-pole design that will provide smoother operation than the average case fan.
The MYSTIQUE liquid coolers feature DeepCool's patented Anti-Leak Technology. The internal valve regulates pressure and will purge it when internal pressure exceeds atmospheric pressure; this leads to a longer useful life while reducing the possibility of leaks.
Technical Specification |
Value |
Net Weight |
1847 g |
Radiator Dimensions |
402×120×27 mm(L×W×H) |
Radiator Material |
Aluminum |
Tube length |
410 mm |
Pump Dimensions |
93×77×66 mm(L×W×H) |
Pump Speed |
3400 RPM±10% |
Pump Noise |
21 dB(A) |
Pump Connector |
3-pin |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.35 A |
Pump Power Consumption |
4.2 W |
Fan Dimensions |
120×120×25 mm(L×W×H) |
Fan Speed |
500~2150 RPM±10% |
Fan Airflow |
72.45 CFM |
Fan Air Pressure |
4.32 mmAq |
Fan Noise |
≤36.49 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Fluid Dynamic Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.3 A |
Fan Power Consumption |
3.6 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
2.45 W (PUMP) |
Display Specifications |
2.83 inch 480×640 TFT LCD |
EAN |
6933412728764 |
P/N |
R-LX750-BKDSNMP-G-1 |
